GE200-12 12V 100Ah Gel Battery – Deep Cycle Power

n

Description of 12V 200Ah GEL Battery

nThe GE200-12 Gel Battery delivers reliable 12-volt power with a 100-amp-hour deep-cycle capacity, making it ideal for solar setups, UPS backup, and off-grid applications. With its sealed gel-electrolyte design, you’ll benefit from maintenance-free performance and long service life.
n

The GE200-12 Gel Battery features advanced gel-battery technology to provide dependable deep-cycle capacity in demanding environments. Because it uses a sealed gel design, it resists leaks, handles tough conditions, and reduces maintenance. Its 12 V/100 Ah rating suits renewable energy systems, standby power, and frequent discharge-recharge use.

n

Moreover, the design includes thick plates and high-density active materials for better recovery after deep discharges. The GE series also meets international standards for reliability and long life, making it a strong choice for both residential and commercial applications.

n
n

Key Features

n

n
• 12 V nominal voltage with 100 Ah capacity at 10-hour rate.

n

• Sealed gel deep-cycle construction — maintenance-free and non-spillable.

n

• Excellent recovery after deep discharge due to robust internal structure.

n

• Suitable for solar power systems, UPS, telecom, standby or frequent use.

n

n

Specification

n

n

n

n
• Rated Voltage: 12V

n

• Number of cells: 6 Cells

n

• Capacity: 200Ah @10hr rate to 1.80V Per Cell @25˚C

n

• Weight: 62.4kg

n

• Internal Resistance: Approx. 3.5mΩ

n

• Terminal: F1 / F2

n

• Max. Discharge Current: 3 00A(5s)

n

• Short Circuit Current: 10000A

n

• Max. Charging Current: 50A

n

• Reference Capacity: C10 200.0AH | C3 144.7AH | C1 110.1AH

n

• Design Life: 10~15 years

n

• Float Charging Voltage: 13.6 V~13.8 V @ 25°C
  n
  n

  n

  n

  n
  nTemperature Compensation: -20mV/°C/Cell
  n
  n

  n

  n

  n

n

• Cycle Use Voltage: 14.4 V~14.9 V @ 25°C
  n
  n

  n

  n

  n
  nTemperature Compensation: -30mV/°C/Cell
  n
  n

  n

  n

  n

n

• Operating Temperature Range: Discharge: -20°C~60°C | Charge: 0°C~50°C | Storage: -20°C~60°C

n

• Normal Operating Temperature Range: 25°C±5°C

n

• Self Discharge: Less than 3% at 25°C per month

n

• Container Material: A.B.S. UL94-HB, UL94-V0 Optional.
